Connector diode - plug - for Solar PV system - inner-knob - auto-lock - waterproof
5,49 €
.
- Connector diode.
- Plug for Solar PV system.
- Auto-lock enable connection more easy and reliable.
- Waterproof and dustproof.
- Long lifetime.
- Rated Voltage: TUV 1000 DC
- Test voltage: 6KV(50Hz,1Min)
- Contact material: copper, tin plated.
- Contact resistance: less than 0.5 m ohm
- Waterproof: IP67
- Pollution degree: 2
- Protection class: Class II
- Flame calss: UL94-V0
- Plug force: less than 50N
- Withdrawal force: more than 50N
- Ambient temperature range: -40°C ~ + 90°C
- Diode: 8 A ~ 15 A
- Pin dimention: 4.0mm
